Trocal PVC Roof Repair in West Hartford, CT

January 19th, 2010

ID Flat Roof is an authorized installer of IB Roof PVC membrane – the best solution for the flat roofs market these days. There are other PVC roofing products on the market but all of them have different weaknesses and none have strengths of IB PVC Roof.

We received a call from a client in West Hartford, CT about the old Trocal roof. Even though the Trocal PVC roofs have been on the market for a while they have one very big issue: they get fragile at the temperatures around zero degrees Celsius (32 F) and exponentially become more and more brittle as temperature drops further. In our case it was a combination of things: very cold weather (which is not that unusual for Connecticut in December-January period) and wind that broke of the branch of the tree near the house. The branch fell on the roof completely shattering 15×6 feet section.

img_1580

We decided to repair that section with IB PVC Membrane – first of all because it is not sensitive to the temperature fluctuations and is very flexible and second because it can be hot air welded to the existing Trocal PVC. We started with cleaning up approximately 25×6 feet section making sure that there are absolutely no cracks left behind. Then we replaced old drip edge and made sure that old insulation and PVC is fastened reliably using 2” barbed plates. The old fasteners weren’t working very well and there were definitely not enough of them. Then old PVC was cleaned using acetone and the pieces of new IB PVC membrane were installed and welded together and to the old PVC.

img_1591

Now the single piece of IB membrane and old Trocal was formed and roof became completely watertight again.

img_1597

IB Roof/Deck Installation in Warren, RI

March 15th, 2010

This is a waterfront house in Warren, Rhode Island facing the bay. The old rubber roof was failing, there were multiple leaks along seams and corners, plus owner complained that it gets pretty hot in the dining room located below during the sunny days.

roof1

roof2

Both these issues were resolved by installing single ply 50-mill white IB membrane. First of all old rubber and insulation were removed and roof deck was inspected for the rot damage. Because homeowner addressed his leak issues in the timely manner no rot damage was found and no repairs were necessary. We installed new ½ inch fan fold insulation and IB membrane on top of it. To properly flash the membrane to the walls 3 rows of siding where removed, membrane was flashed 1 foot up to the wall and a few inches into the gap under the sliders.

img_1900-1600x1200

img_1899-1600x1200

After the siding was reinstalled and all the gaps sealed, leaking problem was taken care of, as well as dining room’s overheating, because white membrane reflects about 90% of sunlight, thus making living areas under it much cooler.

IB Roof Installation in Lynn, MA

March 9th, 2010

Even though this was a relatively big two family house with the roof being about 1200 sq. feet it only had one 3 inch drain in the middle of it – that was just the way houses were built back in the days. The roof was originally tar & gravel and naturally, after installing couple more new layers, it lost its slope towards the middle of the roof where drain is. That, of course, caused water to pond making the situation even worse and resulting in multiple leaks. Roofing contractor who was called for repair charged $3500 and installed another patch right where water was ponding – naturally, story repeated itself in no time. So, when we met the owner he was very frustrated and angry about the whole story – costly repairs were done but with no improvements.

img_1381

We decided to strip top two layers, recreate original slope and install 50 mill IB PVC membrane over ½ inch fan-fold insulation.

img_1425

After the strip was done we discovered that because water was getting under the roof for a long time there were multiple places were roof deck was completely rotten and deteriorated, we even found a termite colony at one place (wood and moisture, talk about better combination for termites!). Another problem was the drain itself: after multiple repair attempts it had some build-up around it making it not the lowest point of the roof.

img_1435img_1436img_1456

After all rot damage was repaired and frame was rebuild we proceeded with installing IB membrane. 6 inch wide pressure treated wood nailer was installed around all edges. Than we installed ½ inch thick insulation and started rolling out IB membrane.

img_1471

Two old vents were removed and replaced with IB vents; both chimneys were wrapped around about two feet high and terminated with masonry anchors and termination bar. After all seams were hot air welded together – forming one continuous piece of membrane – it was a time to replace the drain. We cut the old piece out and installed new 3 inch IB drain with rubber gasket to prevent possible back-flow and aluminum dome over it to prevent it from clogging with leaves and other debris.

img_1579

As a result – nice watertight roof, no ponding water and one happy customer.

img_14871

IB Roof Installation in Darien, CT

February 9th, 2010
